Being a well-recognized organization, we are proposing the best Fix Foam Concrete Road Finisher. The machine is designed for making finishing of concrete road quicker, and easier. Easy to operate, highly efficient, low maintenance and robust construction, it consumes less fuel or energy while functioning due to its high quality road finishing mechanism and ergonomic design. Further, Fix Foam Concrete Road Finisher is available with optional accessories like longitudinal & transverse polyvinyl chloride water stop inserter attachment, longitudinal & transverse groove cutter, slope wedges, transport assembly, and fabricated rail.
Technical Specification:
Prime Mover | |
Driver End Panel | 5 HP Geared Motor |
Vibratory Cylinder | 5 HP Geared Motor |
Bogie RH & LH | 1 HP + 1 HP Geared Motor |
Vibratory Cylinder | 1 HP Electric Motor |
Traction System | |
Traction Drive | Two Electrically driven double flanged bogie wheels |
Traction Speed | 0-22 rpm |
Vibratory Cylinder Under Carriage | |
Finished Cylinder 270 mm dia., 1.2 Mtr. long precisely balanced | |
Extra Long Screw Augur (RH & LH) with hardened flights | |
Finishing Tolerance: +-3 mm in 12 ft. | |
Machine Controls | |
Adjustable Carriage Movement with Variable Speed Drive | |
Shock Protection | |
Overload Protection | |
Construction | |
Frame: All welded, pin connected main frame. Available in length of 2.40 mtr., 1.2 mtr,, 0.6 mtr., which are infinitely adjustable up to 62 ft. and 110 ft. | |
Finishing Width: Finishing width normally 3ft. (0.9 mtr.) less than frame width and adjustable from lmtr. to 32 mtr. |
