CCP Series Mobile Concrete Batching Plant is designed to give discharge height of 2M from the ground level, making it ideal for utilizing concrete pump and transit mixer on site where there plant is shifted commonly at different site location in order to meet the concrete need. It is a fully automatic mobile kind batching plant with whole plant assembly on single chassis with the facility of tow bar. With tractor single operator can conveniently move the plant on site and effortless to erect and commission the plant because it does not require to make foundations. CCP Series Mobile Concrete Batching Plant is also has control panel on the same chassis along with inbuilt water tank and internal cabling.
Technical Specification:
Model | CCP 20 | CCP 25 | CCP 30 | CCP 45 |
Output capacity | 20 Mcube/ Hr. | 25 Mcube/ Hr. | 30 Mcube/ Hr. | 45 Mcube/ Hr. |
Mixer type | Pan type mixer/ Planetary mixer/ Twin Shaft mixer | |||
Main mixer drive | 20 HP | 25 HP | 30 HP | 40 HP |
Material storage system | 2 x 2 Cross bin feeder | |||
Material storage capacity | 12 M | 12 M | 14 M | 20 M |
Material weighing system | Digital load cell based weighing of aggregates, cement ,water and additive | |||
Control panel | PLC based control panel with internal cabling | |||
Total connected power | 45 HP | 50 HP | 58 HP | 79 HP |
Suggested DG Set | 50 KVA | 62 KVA | 82 KVA | 100 KVA |
Concrete discharge Height | 2.1 Meter from the ground level |
