RMV Series Reversible Mixer Venus Feeding System
1800000 INR/Unit
Product Details:
- Product Type Reversible Mixer
- General Use Industrial, Construction
- Material Metal
- Type Concrete Mixing Plant
- Automatic Yes
- Control System PLC Control
- Power Consumption 35-43 Horsepower (HP)
- Click to View more
X
RMV Series Reversible Mixer Venus Feeding System Price And Quantity
- 1800000 INR/Unit
- 1 Unit
RMV Series Reversible Mixer Venus Feeding System Product Specifications
- Blue
- 12-15 Cubic Meter (m3)
- 35-43 Horsepower (HP)
- High Efficiency High Speed
- Reversible Mixer
- Metal
- PLC Control
- Concrete Mixing Plant
- Industrial, Construction
- Yes
RMV Series Reversible Mixer Venus Feeding System Trade Information
- Cash Advance (CA)
- 5 Unit Per Day
- 1 Week
- All India
Product Description
Backed by years of industry experience and talented professionals, we have been able to presenting a world-class RMV Series Reversible Mixer Venus Feeding System. It is utilized on many different construction sites for mixing and discharging the concrete. Featured with forward rotation of the drum and reverse rotation of the drum functionalities, it is made of top of the line material with latest technology as per industry standards. Besides, RMV Series Reversible Mixer Venus Feeding System is available in new and innovative models at compromising prices.
Technical Specifications:
| Description | RMV 12 | RMV 15 | RMV 20 |
| Output Capacity | 123/Hr. | 153/Hr. | 203/Hr. |
| Batch Capacity | 400 litre | 500 litre | 670 litre |
| Batch Cycle Time | 120 Sec. | 120 Sec. | 120 Sec. |
| Main Mixer Type | Reversible Drum Type Mixer | ||
| Mixing and Discharge Of Concrete | Forward rotation of the drum mixes the material and reverse rotation of the drum discharge the concrete | ||
| Main Drive Of Mixer | 10 HP | 15 HP | 20 HP |
| Material Storage System | Unique three separate bin for storing different aggregates | ||
| Material Feeding System | Through inclined belt conveyors | ||
| Material Weighing System | Digital load cell based accurate weighing system | ||
| Material Storage Capacity | 12 M 3 | 15 M 3 | 15 M 3 |
| Cement Storage hopper | 40 Bag | 40 Bag | 40 Bag |
| Cement Feeding System | Through inclined screw conveyor driven by geared motor | ||
| Cement Weighing System | Digital load cell based weighing of cement in separate hopper | ||
| Water Feeding System | Auto water dozing system | ||
| Water tank capacity | 200 litre | 250 litre | 300 litre |
| Admixture dozing system | Auto admixture dozing system | ||
| Control Panel | Fully automatic PLC based control panel with internal cabling | ||
| Total connected power | 35 HP | 38 HP | 43 HP |
| Suggest D.G. Set | 42 KVA | 50 KVA | 62 KVA |
| Concrete Discharge Height | 1.2 meter | 1.5 meter | 1.7 meter |
